Workswell

SAFETIS Stainless Steel Detect Flare-Ups before fire starts

Model No :

SAFETIS Stainless Steel

Part Code :

WSS-336-S/F(9Hz, 30Hz)WSS-640-S (9Hz)

Overview

Fire Prevention: SAFETIS Stainless Steel is designed for fire detection and protection such as to detect the risk of flare-up before flames brakout.SAFETIS cameras can be used and controlled via integrated Web-server or via SAFETIS Control Unit with advanced features Workswell SAFETIS Stainless Steel camera offers great resolution of 640 x 512 px, sensitivity of 50 mK (0.05 °C) and fast response within milliseconds

Features

Resolution 336 px or 640 px detector up to 30 Hz
Advanced analytics, recording and alarming
Fully calibrated up to 550 °C (optional +1 500 °C)
Infinity focus or optional focusing on target
SAFETIS Control unit for advanced visualization
Built-in web-server for control and stream
High-protection heated outdoor housing IP67
Fully calibrated up to 550 °C (optional +1 500 °C)

Major Applications

-Industrial warehouses
-Ammunition warehouses
-Coal warehouses and conveyors
-Power plants and electric energy distribution systems
-Agricultural warehouses, food warehouses

Technical Specifications

Resolution: 336 x 256 pixels, 640 x 512 pixels
Image frequency: 9 Hz or 30 Hz
Temperature sensitivity: 0.05 °C (50 mK, 0.09 °F)
Spectral range: 7.5 – 13.5 µm

General Specifications

Temperature ranges:
-25 °C to +150 °C (-13 °F to +302 °F)
-40°C to +550 °C (-40 °F to +1022 °F)
Optional extended temperature range:
+50 °C to +1 000 °C (+122 °F to +1832 °F) (filter)
Optional extended temperature range:
+400 °C to +1 500 °C (+752 °F to +2732 °F) (filter)

Catalogue

https://www.elmack.co.in/images/downloads/Catalogue/safetis stainless steel.pdf

Manufacturing details:

https://workswell-thermal-camera.com/workswell-safetis-stainless-steel-thermal-camera-specially-cons
